| AutoKut 160 | ||
| Maximum Material Width | 49.25” / 1250 mm | |
| Minimum Material Width | 8” / 200 mm | |
| Maximum Slitting Capacity Mild Steel | 16 gauge / 1.6 mm | |
| Slitting Capacity Stainless Steel | 20 gauge / 1 mm | |
| Slitting Capacity Aluminum | 0.080” / 2 mm | |
| Maximum Blanking Capacity Mild Steel | 14 gauge / 2.0 mm | |
| Blanking Capacity Stainless Steel | 18 gauge / 1.25mm | |
| Blanking Capacity Aluminum | 0.125” / 3 mm | |
| Number of Straightening Rolls | 5 (3 over 2) | |
| Minimum Slit Width | 2 3/8” / 60 mm | |
| Minimum Edge Trim | ¼” / 6.4 mm | |
| Number of Slitting Knives | 5 | |
| Slitting Speed Variable | 115 FPM / 35 MPM | |
| Drive Motor | 4 hp / 3 kw | |
| Guillotine Motor | 3 hp / 2.2 kw | |
| Machine Weight | 4,410 lbs / 2,000 kg | |
| Machine Dimensions L x W x H | 74.5 x 65.5 x 46” | |
AutoKut 160
The heavy-duty AutoKut 160 is ideal for customers seeking increased slitting and blanking capacity in a compact machine. The AutoKut 160 features automatically-controlled slitting shaft adjustments, straightening rollers, and feed rollers, streamlining processing. It is designed for long-term serviceability with all mechanisms outside the machine and does not require disassembly for blade changes. The AutoKut 160 accommodates coils up to 49.25″ wide and can slit up to 16 gauge mild steel and blank up to 14 gauge. It comes standard with 5 pairs of easily-repositioned slitting blades and offers an approximate 1-second shear cycle time.
Description
Additional information
| Weight | 4410 lbs |
|---|---|
| Dimensions | 74.5 × 65.5 × 46 in |
